T-MOTOR MT2814 KV710 770 (2pcs)

T-MOTOR MT2814 KV710 770 (2pcs)

0 (0 reviews)
SKU: 2509 (Added on 05/30/2017)
Price:
Stock: 28
Weight: 300 g
KV:

Specifications:

KV..............................................................................................................710
Configu-ration.................................................................................12N14P
Stator Diameter.................................................................................28mm
Stator Length.....................................................................................14mm
Shaft Diameter....................................................................................4mm
Motor Dimension(Dia.*Len).................................................Φ35×36mm
Weight(g)..............................................................................................120g
ldle current(10)@10v(A)......................................................................0.4A
No.of Cells(Lipo)..................................................................................3-4S
Max Continuous current(A)180S.........................................................27A
Max Continuous Power(W)180S.....................................................440W
Max. efficiency current...........................................................(6-18A)>83%
internal resistance..........................................................................125mΩ





Specifications:



KV..............................................................................................................770



Configu-ration...................................................................................12N14P



Stator Diameter....................................................................................28mm



Stator Length........................................................................................14mm



Shaft Diameter.......................................................................................4mm



Motor Dimension(Dia.*Len)....................................................Φ35×36mm



Weight(g).................................................................................................120g



ldle current(10)@10v(A)..........................................................................0.5A



No.of Cells(Lipo).....................................................................................3-4S



Max Continuous current(A)180S............................................................29A



Max Continuous Power(W)180S........................................................500W



Max. efficiency current..............................................................(6-19A)>81%
internal resistance..............................................................................100mΩ





All packages are sent without our website logo or any information indicating about us.
